EPCOS B43564-S9588-M2 Aluminum Electrolytic Capacitor, 5800µF 400V, Screw Terminal, - Pack of 12

EPCOS B43564-S9588-M2 Aluminum Electrolytic Capacitor (5800µF, 400V)

The EPCOS B43564-S9588-M2 is an industrial-grade, large-can aluminum electrolytic capacitor engineered for mission-critical power electronics systems. Delivering a substantial capacitance of 5800µF at a high voltage rating of 400V, this component is designed for maximum performance and reliability. Its key features include an extremely high ripple current capability and a very long useful life, making it the ideal choice for demanding applications such as DC link filtering in frequency converters, buffering in industrial power supplies, and energy storage in renewable energy inverters. The robust screw terminal design ensures secure, low-resistance connections essential for high-power circuits.

Manufacturer Information:

• Manufacturer: EPCOS (A TDK Group Company)
• Part Number: B43564-S9588-M2 (Also commonly referenced as B43564S9588M2)
• Product Type: Aluminum Electrolytic Capacitor
• Capacitance: 5800 microfarads (µF)
• Rated Voltage: 400 Volts Direct Current (VDC)
• Tolerance: ±20% (Indicated by the "M" suffix in the part number)
• Series: B43564 (Characterized by very long useful life and high ripple current capability)
• Termination Type: Screw Terminals
• Useful Life: 12,000 hours at +85 °C (Per manufacturer datasheet)
• Operating Temperature Range: -40 °C to +85 °C
• ESR (Equivalent Series Resistance): Extremely low ESR at operating frequencies (e.g., typically ≤ 21 mΩ at 100 Hz, 20 °C)
• Standards: Manufactured to comply with relevant industrial standards such as IEC 60384-4.
