ABB AX09-30-01 3Pole Contactor (2 Pieces)

Brand: ABB
Product Name: Contactor
Catalog Number: AX09-30-01-81
Product ID: 1SBL901074R8101
EAN: 3471522392817

Overview

The ABB AX09-30-01-81 Contactor is a versatile and reliable block type contactor, specifically designed for controlling 3-phase motors and power circuits up to 690 V AC. As part of the AX09 to AX25 series, this contactor is engineered for robust performance in industrial and commercial applications. It features a compact design with 3 main poles and a built-in normally closed (NC) auxiliary contact, providing essential control and feedback capabilities. The contactor is AC operated, with a 24V 50/60Hz control voltage making it suitable for low-voltage control systems. Its modular design allows for easy expansion with add-on auxiliary contact blocks (for front or side mounting), enhancing its adaptability to diverse control schemes.

Key Features

• 3 Main Poles: Ideal for switching and controlling 3-phase AC loads, including motors.
• Integrated Auxiliary Contact: Includes 1 built-in normally closed (NC) auxiliary contact, simplifying wiring for control circuits and status indication.
• High Voltage Capability: Suitable for power circuits up to 690 V AC, ensuring broad application versatility.
• AC Operated Coil: Designed for a low control voltage of 24V AC at 50/60Hz, ideal for low-voltage control systems and safety applications.
• Block Type Design: Offers a compact footprint and robust construction for reliable operation.
• Expandable Auxiliary Contacts: Supports front or side mounting add-on auxiliary contact blocks, allowing for flexible configuration of control and signaling circuits.
• ABB Quality & Reliability: Manufactured by ABB, a global leader in electrification, guaranteeing high standards of performance and durability.

Technical Specifications
