kaiertfuse 40A Fast-Acting PV Fuse - 700VDC (KHD0-40A DIN0 109PV4035)
kaiertfuse 40A Fast-Acting PV Fuse - 700VDC (KHD0-40A DIN0 109PV4035)
Kaiert offers a wide selection of high quality 700VDC rated PV fuses for providing overload and short-circuit protection in photovoltaic systems. With amp capacities ranging from 16A up to 250A, these fast-acting fuses feature compact ceramic or glass tube construction with advanced fusible silver links.
These versatile fuses can be easily mounted via DIN rail or onto panels for installation in PV combiner boxes, junction boxes and string fuse applications. They deliver reliable performance with total I2t clearing values up to 56,000A2s and interrupting ratings up to 63kA. Depending on amp rating, power losses range from 3.5W to 24W.
Certified to meet latest safety standards, these 700VDC PV fuses minimize fire hazards and prevent expensive solar equipment damage. With blown fuse indication and global approvals, Kaiert's extensive fuse range offers optimal protection for diverse DC solar needs up to 700VDC.
Please contact us regarding customization, special requirements or technical support for integrating Kaiert's high-quality PV fuses into your solar products and power systems.
